Thuraya – IP

Caratteristiche generali

Weight

• 1.3 kg terminal and battery

Size

• 158mm x 225mm x 50mm

IP Data Services

• Standard IP
  • Up to 444 kbps over a shared channel
• Streaming IP
  • Without External Antenna: 16, 32, 64, 128, 256* kbps
  • With External Antenna: 16, 32, 64, 128, 256, 384 kbps

Tolerances

• Opening Temperature
  • Running from external supply: -25° to +55° C
  • Running from battery: 0° to +50° C
• Storage Temperature
  • Including battery: -20° to +60° C
  • Excluding battery: -40° to +80° C
• Operating Humidity
  • 95% RH at 40°
• Mechanical Vibration
  • 200-2000 Hz, 0.3 m2/s3
• Unpacked Drop
  • 0.5m on concrete surface
• Water & Dust Proofing
  • IP55 standard

Power

• External Power
  • Main power supply adapter, 100-240 V AC at 50-60 Hz
• Input Voltage
  • 12 V DC

Battery

• Battery Life
  • Up to 36 hours standby time
  • 1 hour of continuous transmission at the highest rate
• Battery Type
  • Lithium-Ion
• Charging Temperature
  • 0° to +40° C

Interfaces

• Connectors
  • Ethernet (RJ-45), USB
• User Interface
  • Web-based graphical user interface accessible via standard web browser
• External Antenna Connector
  • GPS, active and passive antenna
• WLAN Connectivity
  • IEEE 802.11b standard with
  • WEO encryption
  • SSID broadcasting control
  • MAC address filtering
  • DHCP
